Specifications:

Finish: 26D

Door Thickness: 1 ¾” (44.5mm) thick standard. For doors over 1 ¾” (44.5mm), specify door thickness

Handing: Lock bodies are easily field reversible, no need to specify hand when ordering

Backset: 2 ¾” (70mm) only backset.

Strike: Brass or stainless steel strike; ANSI Standard A115.1; curve lip with dust box

Lock Case: Heavy Duty wrought steel, zinc dichromate plated

C to C: Center of lever to center of cylinder is 3 7/8” (98mm)

Armor Faceplate: Brass or stainless steel; 8” x 1 7/32” (203mm x 31.3mm); ANSI Standard A115.1

Deadbolt: 1” (25.4mm) throw; hardened stainless steel

Latchbolt: 3/4” (19mm) throw; one-piece stainless steel with anti-friction reversible tongue

Cylinders and Keyways

6-pin solid brass “C” keyway standard. Optional: Schlage E, Schlage C-K,

Russwin D1-2-3-4, Corbin 59/60, Corbin-Russwin L4, Sargent LA-LB-LC,

Falcon/Weiser E, Arrow A, Yale 8, Yale GA and Kwikset. Can also accept

Medeco, Assa, Kaba and Cal-Royal HSK High Security Cylinders

Interchangeable Cores (IC)

Interchangeable Core locks will accept compatible 6 or 7 pin cores with BEST,

FALCON and ARROW. Also available with SCHLAGE, large format cylinders

Toggle Button: High rust-resistant chrome plated zinc alloy

Master Keying: Can be master-keyed or grand master-keyed, construction keying available

Auxiliary Latch: Stainless Steel, non-handed

Certifications:

ANSI/BHMA Meets ANSI/BHMA A158.13 Series 1000 Grade 1 requirements.

UL / cUL UL and UL Listed to Canadian safety standard for A label (3-hour fire door); stamped letter F and UL symbol on armor faceplate

POSITIVE PRESSURE Meets positive pressure requirements UL 10C and UBC 7-2 (1997)

ADA APPROVED Meets ADA requirements, specifically designed for Barrier Free Application
